Specification.
KSU Crushed Coal Specifications I
|
Parameter |
Coking Coal Products % (a.d) |
||
| Moisture% (a.d) | 2.5 | 2.5 | 2.5 |
| Ash% (a.d) | 7 | 7 | 7 |
| Volatile Matter%(a.d) | 33 | 33 | 33 |
| Total Sulfur % (a.d) | 1.5 | 1.8 | 2.3 |
| Calorific Value Kcal/kg (a.d) | 7,500 | 7,500 | 7,500 |
| CSN | 7-9 | 7-9 | 7-9 |
| GieselerPlastometerddpm | Typical 20,000 | Typical 20,000 | Typical 20,000 |
KSU Crushed Coal Specifications II Typical
| Gieseler Plastometer Details | ||
| Initial Softening | oC | 375 |
| Maximum Fluidity | oC | 4467 |
| Maximum Fluidity | ddpm | 22406.1 |
| Maximum Fluidity | log 10 | 4.35 |
| Final Fluidity Temperature | oC | 483 |
| Solidification | oC | 491 |
| Plastic Range | oC | 116 |
KSU Crushed Coal Specifications III Typical
| Ash Fusion Temperature(Reducing Atmosphere) | ||
| Deformation | oC | 1030 |
| Spherical | oC | 1090 |
| Hemispherical | oC | 1230 |
| Flow | ||
| Ash Fusion Temperature | ||
| (Oxidizing Atmosphere) | ||
| Deformation | oC | 1240 |
| Spherical | oC> | 1270 |
| Hemispherical | oC | 1360 |
| Flow | oC | 1440 |
